ÖZELLİKLER
Technical Data
Speaker Type 2-Way Active Speaker
Acoustical data
Usable Bandwidth [-10dB] 67 - 20.000 Hz
Frequency Response [- 6dB] 73 - 20.000 Hz
Max SPL 132 dB
HF 1" Exit, 1.75 v.c.
Horizontal Directivity 100° (85° up/120° down)
Vertical Directivity 85° (+ 25°/-60°)
Horn Asymmetrical Horn
LF 12", 3" v.c.
Amplifier
Amp Technology Class D DigiproG3
RMS Power 900 W
Peak Power 1800 W
Processor
Controller DSP 56 bit
AD/DA Converter 24 bit/48 KHz
Controls
Rotary Encoder (8 Presets)
1x Input Sensitivity
1x Power ON led
1x Signal led
1x Limiter Led
1x Status Led
CrossOver Frequency 1600 Hz
Limiter Peak, RMS, Thermal
Advanced DSP Functions Linear Phase FIR Filters
Delay Option 58.6 ms max (via RD Net)
Input
Signal Input
1x XLR Female
1x USB (data service)
Signal Output
1x XLR Male
Mechanics
Housing Polyporpylene PP
Handles 1 on left Side, 1 on Top
Rigging Points 2XM10 on Top + 1x M10 on Back
Pole Mount D36 mm
Angles up Monitor use 45°
Width 350 mm (13.78 in)
Height 642 mm (25.28 in)
Depth 349 mm (13.74 in)
Weight 15 kg (33.07 lbs)
