Playable Formats / File Systems
CD: CD-DA (CD-TEXT), CD-ROM (ISO9660), CD-R, MP3-CD
USB: FAT16 / FAT32
MP3 Format Supported
Extension: MP3
Bitrate: 32 to 320 kbps and VBR
Sampling Frequency: 44.1 kHz\16-bit
Tempo control
Tempo range from -15% to +15%
Tempo lock feature
Number of Channels: 2 (stereo), 1 (mono)
Frequency Response: 20 Hz - 20 kHz (± 1.0dB)
S/N Ratio: > 95 dB (A-Weighted)
Total Harmonic Distortion (THD): < 0.01%
Dynamic Range: > 85 dB
Channel Separation: > 80 dB
Input
Aux in: TRS (3.5mm)
Input impedance: Over 10kΩ
Maximum input level: 1 Vrms
Output
Balanced XLR / unbalanced RCA
Maximum output level: 3 Vrms
USB Thumbdrive Specs
Max storage capacity: Up to 32 GB
Max file size: 2 GB
Operating Environment
Operating temperature: 5-35 degrees Celsius (41-95 degrees Fahrenheit)
Operating humidity: 25-85%, no condensation
General
Power Supply
USA & Canada: AC 120V, 60 Hz
EU, UK, APAC: AC 230V, 50/60 Hz
Japan: AC 100V, 50/60 Hz
Power consumption: 30W
Dimensions
19.00” x 13.66” x 1.73” / 483 x 347 x 44 mm (with rack ears)
17.09” x 13.66” x 1.73” / 434 x 347 x 44 mm (without rack ears)
