TEKNİK ÖZELLİKLER
Mixing channels 24 Line Inputs (16 mono and 4 stereo)
GROUP 4 GROUP Buses + ST Bus
AUX 6 AUX Sends + 2 FX Sends
MATRIX 1 Matrix out
On-board processors FX1:REV-X(8 PROGRAM, PARAMETER control)/ FX2:SPX(16 PROGRAM, PARAMETER control)
Mic inputs MIC: 16 (INPUTS HPF: 100Hz 12dB/oct)
Phantom power 48V phantom power per channel
Line inputs LINE: 16 mono + 4 stereo, CH INSERT: 16 RETURN: 1 stereo
Total harmonic distortion 0.02% (20Hz-20kHz@ +14dBu)
Frequency response +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz
Equivalent input noise -128 dBu Equivalent Input Noise
Residual output noise -94 dBu Residual Output Noise
Crosstalk -74dB @ 1kHz
Power requirements 100-240V 50Hz/60Hz
Power consumption 86W max
Dimensions 819mm x 169mm x 565mm
Net weight 15.5kg
