TEKNİK ÖZELLİKLER
Speaker Type 2-Way Active Speaker
Frequency Response [-10dB] 52 - 20.000 Hz
Frequency Response [- 3dB] 67 - 19.600 Hz
Max SPL 129 dB
HF 1" Exit, 1.4 v.c.
Type HF Compression driver
Horizontal Directivity 100° (85° up/120° down)
Vertical Directivity 85° (+ 25°/-60°)
Horn Asymmetrical Horn
LF 12", 2" v.c.
Amp Technology Amp SMPS Power supply dual range
Amp Class Class D
RMS Power 600 W
Peak Power 1200 W
Controller DSP 56 bit
AD/DA Converter 24 bit/48 KHz
System Presets Rotary Encoder (8 Presets)
CrossOver Frequency 2000 Hz
Limiter Peak, RMS, Thermal
Advanced DSP Functions Linear Phase FIR Filters
Signal Input 1xCombo (XLR/Jack 6.3 mm) MIC/Line
Signal Input 1xCombo (XLR/Jack 6.3 mm) MIC/Inst
Signal Output 1x XLR Male (CH1 Link/Mix OUT)
Signal Output Selectable
Width 350 mm (13.78 in)
Height 642 mm (25.28 in)
Depth 349 mm (13.74 in)
Weight 14.3 kg (31.53 lbs)
