TEKNİK ÖZELLİKLER
System Type 12" 2-way, Bi-amp Powered Speaker, Bass-reflex Type
Frequency Range (-10dB) 55Hz ~ 20kHz
Frequency Response (-3dB) 60Hz ~ 18kHz
Coverage Angle H90°×V60°
Crossover Type FIR-X tuning (linear phase FIR filter)
Crossover Frequency 1.7kHz
Maximum SPL (peak) IEC noise @ 1m 134dB SPL
Amplifier
Amplifier Type Class-D
Power Rating 1300W
Low-Frequency 850W
High-Frequency 450W
Cooling Natural Convection
HPF Frequency 120Hz (-6dB) 24dB/oct
Connectors Input XLR-3-31 x1 (Balanced) TRS Phone Jack x1 (Balanced)
Connectors XLR-3-32 x1 (Balanced) Parallel connection with INPUT
Power Consumption 1/8Power 100W
Magnet Materials Neodymium Magnet
Voice Coil Diameter 3"
High-Frequency 2" Titanium diaphragm compression driver
Magnet Materials Neodymium Magnet
Dimension (W x H x D) 370×638×368mm (14 5/8"x25 2/8"x14 4/8")
Weight 21.2kg
